NETSTAL - Drinktec Preview

Drinktec 2022: NETSTAL presents new PET-LINE 3000


At drinktec NETSTAL will present the new PET-LINE 3000, producing CSD preforms with a thread for tethered caps. By extending the series, the Swiss company is increasingly establishing itself in the market for preform systems with side removal. Thanks to innovative features, users benefit from higher productivity and lower manufacturing costs.

Advertisement
OttoSystems_04_23

At drinktec, NETSTAL will present the new PET-LINE with side entry to the international trade audience for the first time as part of an exhibition appearance. The market launch of the new series already took place in the fall of 2020 with models of 4000 kN clamping force or molds with up to 128 cavities. Now NETSTAL has expanded the portfolio to include variants with 3000 kN and is bringing a PET-LINE 3000-4000 to its booth in Hall C5. The system is suitable for molds with up to 96 cavities and impresses with its particularly fast lock-to-lock time of just 1.9 seconds. "Our strategy of re-sorting the market situation in the side-entry system sector is paying off. With the new PET-LINE, we are now winning significantly more new customers than before. The system convinces customers with lower manufacturing costs per preform. To reach further target groups soon, the 5000 kN model is already under development," says Renzo Davatz, CEO of NETSTAL and member of the Executive Committee of the KraussMaffei Group. The new PET-LINE 3000 can already be ordered and the first models are already running successfully at customer sites. NETSTAL will supply separate information on the sales launch of the larger PET-LINE 5000 later.

Fully compatible, higher productivity and less energy consumption

"In the production environment, the new PET-LINE was compared with similar machines from other manufacturers. Existing 96-cavity molds and post-mold-cooling stations were used in the tests. Energy consumption was reduced by 20-25% with the new PET-LINE. At the same time, material throughput increased due to the faster cycle time. The customer produced more preforms per unit of time at significantly lower electricity costs," explains Stefan Kleinfeld, PET Product Manager at NETSTAL. The considerable energy savings are the result of many innovations developed and implemented at NETSTAL. In addition to the latest generation of drives and inverters, the electric toggle without ball screw and adaptive control play a key role. Thanks to the adaptive controllers, the machine independently adjusts the parameters to the process. "The PET-LINE learns the weight of the mounted take-out gripper and automatically optimizes the driving profiles for fast removal. Furthermore, the machine performs an independent estimation of the mounted mold weight and optimizes the movement time for optimal opening and closing movements. Since the drives are always equally loaded in the process, an elevated level of efficiency is achieved and the power yield is higher," says Stefan Kleinfeld.

Advertisement
Piovan Nov_24

CYCLE GUARD and integrated preform quality control

The CYCLE GUARD also contributes to this by reliably preventing non-removable preforms, so-called short shots, in harsh industrial environments with unstable power grids, thus ensuring maximum system availability. The optionally available safety function permanently monitors the power supply to the injection molding machine and, if necessary, provides sufficient energy to bridge power failures in the millisecond range. In case of prolonged power failures, the current cycle is completed in a controlled manner. The preforms are finished and ejected from the cores of the mold. Injection for the next cycle is interrupted and the entire system is stopped in a controlled manner. As soon as the power is back, production can be resumed after a short system check. CYCLE GUARD works without batteries and is particularly low-maintenance and cost-effective in operation.

The integrated Pecolux inspection system from IMD Vista monitors and documents preform quality in real time. Quality deviations are checked in continuous inline operation. The system checks key features of the preform such as the gate and the thread. In addition, the preforms are checked for color differences, black specs, bubbles and crystallinity. Thanks to the fast feedback and compact integration into the post-mold-cooling unit, this solution is a particularly intelligent and economical inspection routine to produce preforms. Users are thus able to document the quality of the produced batches to their customers at any time.

"The successful launch phase of the new PET-LINE with side removal has given us a thoroughly positive mood. The good compatibility with existing molds, the particularly low energy consumption, as well as low AA values and the fastest cycle times have been attested from all sides. Up to 100% rPET, but also combinations with flakes, colors, and additives, are processed stably and gently within a large process window," emphasizes Stefan Kleinfeld.

Sustainable preform with thread for tethered caps

NETSTAL is producing 10.5 g lightweight CSD preforms for 0.5-liter PET bottles at its booth. The high-performance mold with 72 cavities comes from mold partner MHT Mold & Hotrunner Technology. Partner company Eisbär Trocknungstechnik from Austria handles material preparation and the dehumidifier. The chiller is provided by Swiss company ef cooling. Equipped with a GME 30.40 thread, the preform already meets the new EU requirement for tethered caps, according to which from July 2024 caps must remain attached to the bottle after opening. This design is intended for disposable bottles, has venting slots, and reduces the amount of material used on the bottle thread and cap. PET granulate from the Neogroup company is processed, which consists of 25% chemically recycled PET. The new PET-LINE 3000 will be producing at drinktec from 10 a.m. to 12 p.m. and from 2 p.m. to 4 p.m. daily. The preforms produced at drinktec are later fed into PET recycling so that new PET bottles will be produced from the material.

NETSTAL at drinktec: Hall C5, Booth 363

www.netstal.com/
